Ultra-bright, pure black
Combine our bright, pure black OLED screen with the powerful intelligence of our Cognitive Processor XR™ and you get pictures closer than ever to real life.
Contrast. Like life itself.
The secret is peak brightness and pure blacks. Suddenly you’ll see all the detail, depth and texture that is often missing from some screens.
Screen speaker, always immersive
As the story unfolds before your eyes, you’ll hear a soundtrack that precisely matches the action. Much the same as in a movie theatre.
Game time. Be invincible.
Our BRAVIA XR™ TVs capture the awesome graphics and soundscapes of today’s games. Want more? Pair with a PlayStation® 5 console for absolute immersion.01
Love entertainment. Love the planet.
Great pictures and sound should never compromise the environment. We work tirelessly to help reduce our impact on the planet.
See what makes this TV special
Power and Energy saving | |
---|---|
Power Requirements (voltage/frequency) | 60 Hz for UL cUL 50/60 Hz for other, AC 120 V for UL cUL AC 110-240 V for other |
Accessories | |
Optional accessories | Camera Unit (CMU-BC1)Depends on country selection |
Accessibility | |
Voice Search | Yes |
Accessibility Shortcut | Yes |
Text Magnification | Yes |
Closed Caption | Closed Caption |
Audio Description (Audio key) | Yes |
Screen Reader | Yes |
Built-in Tuner | |
TV System (Digital Sat) | - |
CI+ | - |
TV System (Digital Cable) | Clear QAM |
Tuner Channel Coverage (Digital Cable) | CATV: 1-135 |
TV System (Digital Terrestrial) | ATSC/ATSC3.0 (NEXTGEN TV) depending on your country/area selection |
Tuner Channel Coverage (Digital Terrestrial) | VHF: 2–13/UHF: 14–69 (2–13/14–36 for ATSC3.0) |
Tuner Channel Coverage (Analog) | VHF: 2-13/UHF: 14-69/CATV: 1-135 |
TV System (Analog) | M |
Number of Tuners (Sat) | - |
Number of Tuners (Terrestrial/Cable) | 1 (Digital/Analog) |
Design | |
REMOTE CONTROL | Standard Remote |
STAND POSITION | Three-way position (Standard position/Narrow position/Soundbar position) |
STAND COLOUR | Dark Silver |
Stand design | Aluminum Edge Stand |
BEZEL COLOUR | Titanium Black |
Power and Energy saving | |
ECO FRIENDLY | Yes |
Design | |
BEZEL DESIGN | Metal flush surface |
Power and Energy saving | |
Power Consumption (On Mode) for Energy Star | - |
Power Consumption (Standby Mode) for Energy Star | - |
Energy Star® compliant | - |
SCREEN SIZE (CM, MEASURED DIAGONALLY) | 210 cm |
Screen Size (inch, measured diagonally) | 210 cm (209.5 cm) |
Power Consumption (in standby) | 0.5 W |
Dynamic Backlight Control | - |
Power Saving Mode / Back Light Off Mode | Yes |
Mercury content(mg) | 0.0 mg |
Presence of lead | - |
Features for PlayStation®5 | |
Auto HDR Tone Mapping | Yes |
Auto Genre Picture Mode | Yes |
Software | |
Auto Calibration with CalMAN® | Yes |
Closed Captions (Analog/Digital) | (Analog) Closed Caption, (Digital) Closed Caption |
Teletext | No |
Sleep Timer | Yes |
On/Off Timer | Yes |
Application Store | Yes (Google Play Store) |
Internet Browser | - |
On/Off Timer | Yes |
Electronic Program Guide (EPG) | Yes |
Voice Search | (Voice Search) Yes/(Built-in Mic) Yes |
BUILT-IN MIC SWITCH | Yes (Left) |
Text Input Language | Yes |
Text Input Language | ENGLISH / FRENCH / GERMAN / HEBREW / ITALIAN / RUSSIAN / SPANISH / VIETNAMESE / JAPANESE |
Display Language | AFRIKAANS, AMH, ARABIC, ASSAMESE, AZE, BEL, BULGARIAN, BENGALI, BOSNIAN, CATALAN, CZECH, DANISH, DEU, GREEK, ENGLISH, SPANISH, ESTONIAN, BAQ, PER, FINNISH, FRENCH, GLG, GUJARATI, HINDI, CROATIAN, HUNGARIAN, INDONESIAN, ISL, ITALIAN, HEBREW, JAPANESE, KAZAKH, KANNADA, KOR, KIR, LAO, LITHUANIAN, LATVIAN, MACEDONIAN, MALAYALAM, MON, MARATHI, MAY, BUR, NOB, NEP, NLD, ORIYA, PANJABI, POLISH, PORTUGUESE, ROMANIAN, RUSSIAN, SOL, SLOVENIAN, ALB, SERBIAN, SWEDISH, SWAHILI, TAMIL, TELUGU, THAI, TGL, TURKISH, UKRAINIAN, URD, UZB, VIETNAMESE, SIMPLIFIED CHINESE, TRADITIONAL CHINESE, ZULU |
Operating System | Android TV™ |
Smart TV | Google TV™ |
On-board Storage (GB) | 32 GB |
Camera | |
CAMERA FUNCTION | Yes(Camera apps) |
Sound (Processing) | |
ACOUSTIC CENTRE SYNC | Yes (Home theatre system, Sony compatible Soundbar) |
Headphone 3D Surround Ready | Yes (with WLA-NS7) |
Camera | |
CAMERA | BRAVIA CAM(Option) |
Sound (Processing) | |
Simulated surround sound | 3D Surround Upscaling |
Sound modes | Standard, Dialogue, Cinema, Music, Sports, Dolby Audio |
Sound processing | No |
FM Radio | No |
Sound (Speakers and Amplifier) | |
Speaker Configuration | Actuator x2, Subwoofer x2 |
Sound (Processing) | |
Dolby audio format support | Dolby™ Audio, Dolby™ Atmos |
DTS audio format support | DTS Digital Surround |
ACOUSTIC AUTO CALIBRATION | Room And User Position Compensation |
VOICE ZOOM | Voice Zoom 2 |
Sound (Speakers and Amplifier) | |
Speaker Type | Acoustic Surface Audio+ |
PICTURE (PROCESSING) | |
Picture modes | Vivid, Standard, Cinema, IMAX Enhanced, Game, Graphics, Photo, Custom, Dolby Vision (Vivid/Bright/Dark), Netflix calibrated, BRAVIA CORE calibrated |
Sound (Speakers and Amplifier) | |
Audio Power Output | 20 W + 20 W + 10 W + 10 W |
PICTURE (PROCESSING) | |
BRAVIA CORE CALIBRATED MODE | Yes |
SENSOR | Light/Colour |
NETFLIX CALIBRATED MODE | Yes |
Motion enhancer (Native Hz) | XR OLED Motion, Auto mode |
Video signal support | HDMI™ signal: 4096 x 2160p (24, 60 Hz), 3840 x 2160p (24, 30, 60, 120 Hz), 1080p (24, 30, 60, 120 Hz), 1080i (60 Hz), 720p (24, 30, 60 Hz), 480p |
Clarity enhancement | Yes |
Colour enhancement | XR TRILUMINOS PRO™, XR Smoothing, Live Colour™ Technology |
CONTRAST ENHANCEMENT | XR OLED Contrast Pro, XR HDR remaster, Dynamic Contrast Enhancer, Pixel Contrast Booster |
Clarity enhancement | XR 4K Upscaling, Dual database processing, XR Super Resolution |
Picture processor | Cognitive Processor XR |
PICTURE (PANEL) | |
Refresh Rate | 120 Hz |
PICTURE (PROCESSING) | |
HDR (High Dynamic Range) compatibility | Yes (HDR10, HLG, Dolby Vision) |
PICTURE (PANEL) | |
Backlight dimming type | - |
Backlight type | - |
ANTI REFLECTION (X-ANTI REFLECTION) | - |
Viewing Angle (X-Wide Angle) | - |
Display type | OLED |
Resolution | 3840 x 2160 |
Connectivity | |
USB playback codecs | MPEG1: MPEG1/MPEG2PS: MPEG2/MPEG2TS (HDV, AVCHD): MPEG2, AVC/MP4 (XAVC S): AVC, MPEG4, HEVC/AVI: Xvid, MotionJpeg/ASF (WMV): VC1/MOV: AVC, MPEG4, MotionJpeg/MKV: Xvid, AVC, MPEG4, VP8.HEVC/WEBM: VP8/3GPP: MPEG4, AVC/MP3/ASF (WMA)/LPCM/WAV/MP4AAC/FLAC/JPEG, WEBM: VP9/AC4/ogg/AAC/ARW (Screen nail only) |
Audio Output(s) | - |
Subwoofer Output(s) | - |
USB | 1 (Side)/1 (Bottom) |
USB HDD Recording | No |
USB drive format support | FAT16/FAT32/exFAT/NTFS |
Headphone Output(s) | - |
Digital Audio (Outputs) | 1 (Bottom) |
Auto Low Latency Mode (ALLM) | Yes (for HDMI™3/4) |
Variable Refresh Rate (VRR) | Yes (for HDMI™3/4) |
HDMI Audio Return Channel (ARC) | Yes (eARC/ARC) |
Features specified in HDMI2.1 | 4K120/eARC/VRR/ALLM |
BRAVIA SYNC (INCLUDING HDMI-CEC) | Yes |
HDMI | 4 (1 Side, 3 Bottom) |
HDCP | HDCP 2.3 (for HDMI™ 1/2/3/4) |
RS-232C Input(s) | 1 (Bottom) |
Composite Video Input(s) | Hybrid with S-Centre Speaker Input x1 (Side, Mini jack) |
APPLE HOMEKIT | Yes |
RF (Terrestrial/Cable) Connection Input(s) | 1 (Bottom) |
IF (Satellite) Input(s) | No |
Component Video (Y/Pb/Pr) Input(s) | No |
APPLE AIRPLAY | Yes |
RJ45 | 1 (Bottom) |
Bluetooth profile support | Version 4.2, HID (mouse/keyboard connectivity)/HOGP (Low Energy device connectivity)/SPP (Serial Port Profile)/Advanced Audio Distribution Profile (stereo audio)/AVRCP (AV remote control) |
CHROMECAST BUILT-IN | Yes |
WI-FI FREQUENCY | 2.4 GHz/5 GHz (for Wi-Fi Direct: 2.4 GHz Only) |
Wi-Fi | Wi-Fi Certified 802.11a/b/g/n/ac |
Dimensions and Weight | |
Shipping Weight | 130 lb/ 59 kg |
Weight with stand | 95.9 lb / 43.5 kg |
Weight without stand | 92.6 lb / 42 kg |
STAND WIDTH (NARROW POSITION) | 27.56 in (700 mm) |
STAND WIDTH (SOUNDBAR POSITION) | 74.13 in (1,880 mm) |
VESA® Hole Pitch(W x H) | 15.75 x 15.75 in (400 x 400 mm) |
STAND WIDTH (STANDARD POSITION) | 74.13 in (1,880 mm) |
DIMENSION OF TV WITH STAND (SOUNDBAR POSITION) (W x H x D) | 74.02 x 44.76 x 16.85 in (1,880 x 1,137 x 428 mm) |
DIMENSION OF TV WITH STAND (NARROW POSITION) (W x H x D) | 72.83 x 43.26 x 16.85 in (1,850 x 1,099 x 428 mm) |
Shipping Dimensions(WxHxD) | 77.5 x 47.13 x 8.63 inch(es) / 1,966 x 1,195 x 216 mm |
Dimensions with stand(WxHxD) | 74.02 x 42.2 x 16.85 inch(es) / 1,880 x 1,072 x 428 mm |
Dimensions without stand(WxHxD) | 72.83 x 42 x 2.09 inch(es)/ 1,850 x 1,067 x 53 mm |
Screen Size | 210 cm (209.5 cm) |
MODEL YEAR | |
Model year | 2023 |
SUMMARY | |
WHAT’S IN THE BOX | AC Power Cord, Batteries, Operating Instructions, Quick Setup Guide, Table Top Stand, Voice Remote Control |
