Rockford Fosgate Power Series Harley-Davidson 6.5 Inch Full Range Fairing Or Tour-Pak Speakers - TMS65

The TMS65 is a full range coaxial speaker designed to fit the fairing speaker locations of the 2014+ model year Harley-Davidson® BOOM!™ Audio and BOOM!™ Audio Stage-I systems.  It features a Neodymium motor structure driving a co-molded, reinforced polypropylene cone with Santoprene surround. It also features an ultra-efficient 25mm dome tweeter with integrated phase plug and is made water/weather resistant with the addition of a Santoprene front isolation spider connecting between the tweeter housing and cone assembly. The speaker mounts using the factory hardware and comes with new grille assemblies.

Overview

The TMS65 full range coaxial speaker is designed for direct fitment application in 2014 and newer Harley-Davidson® motorcycle in both the fairing and Tour-Pak locations. This speaker directly replace the existing factory speakers using the factory mounting hardware and speaker connectors. It features a compact Neodymium motor structure driving a co-molded, reinforced polypropylene cone with Santoprene surround This ensures that you get maximum frequency response and output in both the mid and low frequency range. It also features an ultra-efficient 25mm dome tweeter with integrated phase plug for crisp clear highs even at highway cruising speeds. It is made water/weather resistant with the addition of a Santoprene front isolation spider connecting between the tweeter housing and cone assembly. The speaker requires no modification of the factory location and comes with new grille assemblies for both fairing and Tour-Pak applications. Harley-Davidson® is a registered trademark of Harley-Davidson Motor Company

• Element Ready design that is weather and water resistant
• Neodymium Tweeter with Integrated Phase Plug and ASA Grill
• Ultra‐Efficient 25mm Proprietary Film Dome Tweeter
• Carbon‐Fiber Re‐Inforced Polypropylene Cone
• Santoprene VAST Surround
• Co‐Molded Cone and Surround
• Santoprene Front Isolation Spider
• Poly‐Cotton Spider
• High Power 35mm Voice‐Coil
• Ultra‐Efficient Neodymium Ring Magnet Motor
• Ultra‐High Temperature Glass Re‐Inforced Polymer Frame
• Integrated Spade Terminals
• Integrated 6dB Crossover with High Power Polyester Capacitor
• Low Profile Coaxial Tweeter Design
• Discreet (Hidden) Tweeter Wire
• Designed for 2014+ Harley-Davidson® Street Glide®/Road Glide® and Tour-Pak
• Grilles for Fairing and rear Tour-Pak included
• 2-Year Warranty

Technologies

Klippel Verified

Klippel is a speaker certification program allowing us to deliver the best possible subwoofers.

CEA-2031 (speakers)

Power handling on Rockford Fosgate speakers conform to CEA-2031 industry standards.

VAST Surround (speakers)

The Vertical Attach Surround Technique significantly increases a subwoofer's effective radiating cone area up to 25%.

Element Ready - Motorcycle Solutions

These models are protected against Dust, UV, Temperature, Water, Corrosion & Vibration.

Anodized Aluminum Voice Coil Former

Rockford Fosgate subwoofers use anodized aluminum voice coil formers that provide superior heat dissipation (up to 100° at full power levels). Unlike traditional plastic substitutions, aluminum acts like a heat-sink to quickly dissipate thermal build-up on the voice coil. This keeps subwoofers cool during high SPL conditions.
