Rockford Fosgate PMX-1

Rockford Fosgate Punch Marine Grade Media Receiver with Dot Matrix Display - PMX-1


Rockford Fosgate Punch Marine Grade Media Receiver with Dot Matrix Display - PMX-1
Rockford Fosgate Punch Marine Grade Media Receiver with Dot Matrix Display - PMX-1
Rockford Fosgate Punch Marine Grade Media Receiver with Dot Matrix Display - PMX-1
Black Friday Sale Now On
Authorized Dealer Price Match Guarantee
Price Match Guarantee
Audiosource offers a price match guarantee for lower priced items on identical in-stock items from competing authorized dealers. Exclusions Apply*.

Price$459.99
Savings$70.00
Our Price $389.99 CAD
Sale Ends : April 30, 2025
On Sale
Buy Online
Availability
Schedule Delivery
Literature

The PMX-1 features a scratch resistant wet bonded display, superior Bluetooth® audio, AUX and USB inputs.  The Element Ready™ design also provides protection against water, dust, and UV rays.

Overview

The PMX-1 features a 9H tempered glass screen optically bonded which allows for optimized viewing of the dot matrix display under all lighting and viewing conditions. The superior Bluetooth® audio features A2DP and AVRCP for better range, easier device pairing and glitch free wireless audio streaming. The flexible AUX and USB inputs enable convenient access to various audio playback formats and charging of your mobile devices.

  • Wet bonded 2.3" Full Dot Matrix LCD Display
  • 9H Tempered Glass Screen
  • A2DP and AVRCP Bluetooth® Wireless Streaming
  • AUX and USB Inputs with USB Charging
  • Compatible with PMX-BTUR Steering Wheel Remote
  • Independent Subwoofer Level Control
  • 7-Band Graphic EQ + PEQ
  • Selectable HP / LP / AP Crossovers with Selectable Slope 12 / 24 dB/Oct
  • Voltage gauge with Low voltage Warning
  • AM / FM / WB Tuner
  • Multi Region Radio Frequencies
  • IPX6 Marine Grade Front Panel
  • FCC, CE and EN60945 Certified
  • 2-Year Warranty

Technologies

Element Ready™ - Source Units

These source units are protected against Dust, UV, Temperature, Water, Corrosion & Vibration.

Built In Bluetooth®

Built In Bluetooth®

USB Playback

This source unit supports playback from a USB device.

MP3 Playback

This source unit supports MP3 file format playback.

ASTM B117 & D4329 Tested

ASTM B117 & D4329 Tested

IPX6 Water Intrusion Rating

IPX6 Water Intrusion Rating

Specifications
Device TypeDigital-Media Receiver
Speaker Outputs (Yes/No)Yes
Bluetooth® (Yes/No)Yes
3.0+EDR, A2DP 1.3
Pandora® Internet Radio (Yes/No)No
SiriusXM-Ready® (Yes/No)No
Multi-Zone/Multi-Source (Yes/No)No
AUX Input (Yes/No)Yes (1 RCA pair)
USB Charging (Yes/No)Yes
Clock (Yes/No)No
TUNER Number Of Presets18 FM / 12 AM / 6 WB
Steering Wheel Control Ready(Yes/No)No
AM TunerRange: 530 - 1710 kHz
Sensitivity: 40 dB
Frequency Response: 45 to 2.4 KHz
FM TunerRange: 87.9 - 107.9 MHz
Sensitivity: 8 dB
Frequency Response. 20 - 15 KHz
MIn. Speaker Impedance2Ω
Frequency ResponseRCA: 20 Hz - 20 kHz
High-Level: 20 Hz - 20 kHz
Output Impedance<500 Ω
Max Output VoltageRCA Front: 2 V
RCA Rear/Sub: 2 V
Signal to Noise RatioRCA 2V: >85 dB
High-Level CEA-2006: >75 dB
High-Level Max Watts: >85 dB
Media FormatsMP3
WMA
AAC
DRM
Channel SeparationRCA: >70 dB
High-Level: >50 dB
Compatible RemotesN/A
Max THD+NHigh-Level: <1.0 @ 4-Ohm
USB Output Current1 A
Operating Voltage9 - 16 VDC
USB Version2.0
Idle Current<2 A
Fuse Rating20 A
DimensionsWidth: 4.5" (11.5 cm)
Face Depth: 1.5" (3.8 cm)
Mount Depth: 2.9" (7.4 cm)
Height: 4.2 (10.6 cm)
Shipping Weight1.22 Lbs. (0.55 Kg)
Back Panel Cutout3" (77 mm)
