| Our Price |
$179.00 CAD
Sale Ends : August 31, 2025 On Sale
|
The VM520EB is part of the 500 Series in Audio-Technica’s new VM cartridge line – a line that harks back to A-T’s early days as a manufacturer primarily of high-end phono cartridges, while also incorporating today’s advanced technology. Like all VM cartridges, the VM520EB is equipped with dual magnets that are positioned to match the left and right channels in the stereo record groove for outstanding channel separation and extended frequency response. The cartridge’s 0.3 x 0.7 mil elliptical bonded stylus tracks the record groove with high accuracy for outstanding audio reproduction. Includes mounting hardware.
Features
| Specifications | |
|---|---|
| Replacement Stylus | VMN20EB |
| Recommended Load Capacitance | 100-200 pF |
| Mounting Feature | Half-inch mount |
| Accessories Included | Four cartridge installation screws (5 mm x 2, 10 mm x 2), two washers, two hexagon nuts |
| Dimensions | 17.3 mm (0.7") H x 17.0 mm (0.7") W x 28.2 mm (1.1") D |
| Mounting | Half-inch |
| Dynamic Compliance | 8 x 10-6 cm/dyne (100 Hz) |
| Static Compliance | 35 x 10-6 cm/dyne |
| Cantilever | Aluminum pipe |
| Stylus Shape | 0.3 x 0.7 mil elliptical |
| Output Channel Balance | 1.5 dB (1 kHz) |
| Output Voltage | 4.5 mV (at 1 kHz, 5 cm/sec) |
| Coil Inductance | 460 mH (1 kHz) |
| DC Resistance | 800 ohms |
| Coil Impedance | 2,700 ohms (1 kHz) |
| Recommended Load Impedance | 47,000 ohms |
| Stylus Construction | Bonded round shank |
| Vertical Tracking Force | 1.8-2.2 g (2.0 g standard) |
| Vertical Tracking Angle | 23° |
| Frequency Response | 20-23,000 Hz |
| Channel Separation | 27 dB (1 kHz) |
| Stylus Size | 0.3 x 0.7 mil |
| Type | VM Type |
| Weight | 6.4 g (0.2 oz) |
