Cerwin-Vega CVP Pro 1-Channel Class-D 5000 Watts Amplifier - CVPRO5K

Overview

CVPRO5K - 1-Channel Class-D Amplifier 5000W

Cerwin-Vega CV PRO Series Amplifiers – Power Unleashed

When only the most intense bass will do, the Cerwin-Vega CV PRO Series Amplifiers deliver the earth-shaking, chest-thumping performance that power-hungry subwoofers demand. Engineered for those who crave unparalleled sound pressure levels, these amplifiers push boundaries with super high-power, high-current performance that dominates the competition.

Power That Packs a Punch

• Monstrous Output: Delivering a jaw-dropping 3000W to 5000W of raw power, these amplifiers fuel your system to produce bass so intense, it feels like a seismic event.
• Designed for Mayhem: Built for subwoofers that demand extreme power to achieve maximum excursion and SPL impact.
• Ultimate Control: Advanced engineering ensures precision and clarity, even at maximum output.

Engineered for the Ultimate SPL Experience

• High-Current Technology: Designed to handle the most demanding loads, delivering consistent performance for bass that never backs down.
• Built to Last: Rugged construction and superior thermal management keep the CV PRO amplifiers cool under pressure, no matter how hard you push them.
• Extreme Flex Potential: Watch your subwoofers flex and shiver like never before, delivering a visceral audio experience that moves you.

Unleash the Beast

Whether you’re competing in an SPL event or just want to feel your music at its most powerful, the CV PRO Series Amplifiers are your ultimate weapon. When it’s time to make the ground pound, these amplifiers don’t just keep up—they lead the charge.

CV PRO – The Power Behind the Performance

When you demand nothing less than the loudest, most intense audio experience, the Cerwin-Vega CV PRO Series is the answer. Feed your power-hungry system and take your bass to the next level—because nothing else comes close.

Specifications

• CVP Series Class D 1 ohms Stable Monoblock Amplifier
• RMS Power Rating:
• 4 ohms: 1900 watts x 1 channel
• 2 ohms: 3000 watts x 1 channel
• 1 ohm: 5000 watts x 1 channel
• Total RMS power output: 5000 watts
• Pulse Width Modulated MOSFET power supply
• LED Power/Protect Light
• Wired remote bass level control included
• Soft start turn-on
• Speaker-level (high-level) inputs
• 3-way protection circuitry (thermal, overload, and speaker short protection)
• Input sensitivity:
• Low level: 0.2 - 5 volts
• Frequency Response: 15 - 20000 Hz
• Total Harmonic Distortion (THD): .1%
• Signal to Noise Ratio: 90 dB
• Variable low-pass filter: 15 - 1000 Hz
• Subsonic filter: 15 - 1000 Hz
• Fuse Rating: 200A
• 1/0 AWG gauge power and ground wiring is recommended for installation.
• Dimensions: 8.85" W x 10.4" L x 2.61" H
