Standards & Performance | |
---|---|
Nominal Load Impedance | 4-Ohm |
Maximum Peak Power Handling - Watts | 450 Watts with packaged crossover network |
Frequency Response | 101 Hz to 34 kHz/ 850 Hz to 33kHz - with inline packaged crossover network |
Crossover Frequency | 6,200 Hz - Acoustic / 4,800 Hz - Electric |
Continuous Power Handling (RMS) - Watts | 100 Watts with packaged crossover network |
CTA2031 Compliant | Yes |
SPEAKER MATERIALS | |
Wire Terminals | Lug Type |
Voice Coil wire | Copper |
Voice Coil Type | Single Voice Coil |
Voice Coil Material | Glass Imide |
Surround Type | Rolled |
Surround Material | Rubber |
Magnet Weight | 4.5 oz |
Magnet Material | Ferrite |
Damper | Aramid Fiber |
Custom Fit Basket | Yes |
Cone Material | Carbon and Mica reinforced Injected Molded Polypropylene - IMPP |
Basket Material | Resin |
SPEAKER FEATURES | |
Unit Size | 3-1/2" / 25mm - Tweeter |
Unit Shape | Round |
Tweeter | 25mm |
Mounting Depth | 1-3/8 inch(es) |
Cut Out dimensions | 3 inch(es) |
Standards & Performance | |
System-Type | Coaxial 2-way |
Sensitivity (1W/1m) | 85 dB |
Tweeter | |
Type | Balance Dome |
Magnet Weight | 0.1 oz |
Magnet Material | Neodymium |
Diaphragm Material | Polyetherimide (PEI) |
