What's in the Box
Warranty | |
---|---|
Warranty (must be purchased from a Authorized Pioneer Dealer) | 1 year |
Tweeter | |
Diameter | 11 mm |
Type | Polyethylene terephthalate (PET) hard dome |
Woofer | |
Mounting Depth | 1-7/8" (Shallow basket) |
Voice Coil wire | Copper |
Voice Coil Bobbin | Glass Imide |
Magnet Weight | 7.41 oz |
Magnet Material | Ferrite |
Basket Material | Iron Plate Press |
Surround Material | Elastic Polymer |
Diameter | 6-1/2" |
Cone Material | Carbon and mica reinforced IMPP |
SYSTEM | |
Frequency Range | 37 Hz to 31 kHz |
Continuous Power Handling (RMS) | 70 Watts |
Maximum Peak Power Handling | 320 Watts |
Nominal Impedance | 4 ohms |
Sound Pressure Level (Sensitivity) | 91 dB (+- 1.5dB) |
System Type | 3-way Coaxial |
